| Acting type |
Double acting |
| Tube I.D. (mm) |
MCRPL: 16,25,32,40 / MCRPLF: 16,25,32,40,50,63 |
| Port size |
MCRPL: M5~G1/4 / MCRPLF:M5~G3/8 |
| No. of port |
3 |
| Medium |
Air |
| Operating pressure range |
0.1~0.78 MPa |
| Ambient temperature |
－10℃ ~ +80℃ (No freezing) |
| Lubrication |
With or Without lubrication |
| Cushion |
With adjustable cushion at both ends |
| Stroke range (※1) |
φ16: 100~3300 mm / φ25~63: 100~5600 mm |
| Sensor switch |
RCAL |
| Sensor switch holder |
HPL |
| Sensor switch band |
※1: Minimum stroke unit 1mm.
※2: The tube isn't airtight, so the cylinder is allowed little leakage.
Before the cylinder is sale, it has passed the standard of leakage test. |
